Tumbler Holder

Print

Material
Stainless Steel AISI 304
(Click here to see our warranty.)

Technical Specifications
Tumbler Holder is manufactured completely from AISI 304 stainless steel. Base is 40mm diameter solid bar and is joined to 2mm thick mounting flange with stainless steel screw. Holder is 2mm thick sheet and 25mm diameter solid bar and is joined to base with no welding providing a secure and aesthetically correct attachment. Concealed mounting flange is 1.25mm thick stainless steel and securely attaches to wall with stainless steel screws and locks with mounting flange with stainless steel locking screw. Tumbler is satin crystal.

Ordering Information

0408.013-30
Tumbler Holder SS 304 – Bright
0408.013-00
Tumbler Holder SS 304 – Satin
